| Brand Name: | GT |
| Model Number: | C04 |
| MOQ: | 1-50 sets |
| Price: | 1100-1770usd/set |
| Payment Terms: | D/A,L/C,D/P,T/T,Western Union,MoneyGram |
| Supply Ability: | 10000/month |
The power swap cabinet is a power swap system specially designed for electric low-speed vehicles (such as electric tricycles, electric motorcycles, electric low-speed four-wheelers, etc.). The system allows users to quickly replace a depleted battery with a fully charged one without having to wait for a lengthy charging process.
| Number of equipment output channels | Four Connector (4KW) |
|---|---|
| Input voltage range | Single-Phase Electricity AC 220V±20% |
| Input voltage frequency | 50HZ ±1HZ |
| Total output power | 16KW |
| Single output power | 4KW |
| Output voltage range (DC) | 30V-100V |
| Single maximum output current range | 65A |
| Battery BMS communication | CAN/RS485 |
| How to use | Scan Code/Card Swipe |
| Communication method | 4G |
| Display | 7-inch Industrial Touch Screen |
| Cooling method | Temperature Controlled Air Cooling |
| Temperature control | Yes |
| Battery BMS monitoring | Yes |
| Battery abnormal warning | Yes |
| Charging connector | Four * 3m |
| Protection | Overload, Overvoltage, Undervoltage, Overcurrent, Leakage, Water Immersion, Lightning Protection, Etc |
| Material and craftsmanship | Thickened Cold-rolled Steel Plate |
| Appearance and craftsmanship | Electrostatic Spraying |
| Protection level | Dustproof And Waterproof IP53/IP54 |
| Charging port | GB/T 20234.2-2015 |
