| Brand Name: | GT |
| Model Number: | C03 |
| MOQ: | 1-50 sets |
| Price: | 950-1150usd/set |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability: | 10000/month |
| Number of equipment output channels | Dual Connector(11KW) | |||
| Input voltage range | Three Phase AC 380V | |||
| Input voltage frequency | 50HZ ±1HZ | |||
| Total output power | 22KW | |||
| Single output power | 11KW | |||
| Output voltage range (DC) | 30V-100V | |||
| Single maximum output current range | 130A-260A | |||
| Battery BMS communication | CAN/RS485 | |||
| How to use | Scan Code/Card Swipe | |||
| Communication method | 4G | |||
| Display | 7-inch Industrial Touch Screen | |||
| Cooling method | Temperature Controlled Air Cooling | |||
| Temperature control | Have | |||
| Battery BMS monitoring | Have | |||
| Battery abnormal warning | Have | |||
| Charging connector | Two * 3m | |||
| Protection | Overload, Overvoltage, Undervoltage, Overcurrent, Leakage, Water Immersion, Lightning Protection, Etc |
|||
| Material and craftsmanship | Thickened Cold-rolled Steel Plate | |||
| Appearance and craftsmanship | Electrostatic Spraying | |||
| Protection level | Dustproof And Waterproof Ip53/Ip54 | |||
| Charging port | GB/T 20234.2-2015 | |||
